Dragino HP0D Outdoor LoRaWAN Full Hotspot Helium HNT Miner

DWM22042602
Rating

HP0D is Outdoor LoRaWAN gateway it supports the miner feature from Helium and has a built-in ATECC608 encryption chip. It can be used as a Helium Full Hotspot for the project.

Center frequency
$560.00
Quantity

Description

The HP0D is an outdoor LoRaWAN Gateway. It lets you bridge LoRa wireless network to an IP network via WiFi, Ethernet, optional 3G or 4G. The LoRa wireless allows users to send data and reach extremely long ranges at low data rates.

HP0D has passed Helium Full Hotspot Approval. It supports the miner feature from Helium and has a built-in ATECC608 encryption chip. It can be used as a Helium Full Hotspot for the project. It also supports Semtech packet forwarder and LoRaWAN Station connection, it is fully compatible with LoRaWAN protocol. HP0D supports two LoRaWAN servers at the same time, users can use HP0D for helium mining and connects max 2 x LoRaWAN servers at the same time.

Dragino already paid HP0D $40 onboarding cost and $10 location cost for each HP0D. It is ready to use for Helium, user only needs to input HNT wallet address and use QR Code to onboarding HP0D when it arrives.

HP0D has pre-configured standard LoRaWAN frequency bands to use for different countries. Users can also customize the frequency bands to use in their own LoRaWAN network.

Features:

Open Source Linux system

RPi4 with 2G /4G or 8G RAM, shipped randomly

Managed by Web GUI, SSH via Internet

Support Semtech UDP packet forwarder

Support LoRaWAN Station Connection

Support Helium Miner

External fiberglass antenna

Firmware OTA

802.3af PoE

Lighting Protection

Remote Monitoring

Support Helium LoRaWAN server and secondary LoRaWAN server

Include prepaid $40 onboarding cost and $10 location cost.

Remote.it remote management.

Order Information

HP0D-XXX

XXX: Frequency Band

868: For Bands: EU868,IN865

915: For Bands: US915,AU915,AS923,KR920

Useful Link:

Datasheet_HP0D_Outdoor_LoRaWAN_HotSpot

HP0D_User_Manual

Certificate
