922.5mhz RFID SAW bandpass filter 920-925mhz 1dB bandwidth 5MHz

DWM22022304
Rating

922.5mhz RFID SAW bandpass filter is for performance optimization of 922.5MHz RFID receiver, it can effectively filter out out-of-band signal, reduce noise and increase dynamic range.

$26.00
Quantity

Description

The filter has a 1dB bandwidth of 5MHz and steep cut-off characteristics.  For performance optimization of 922.5MHz RFID receiver, it can effectively filter out out-of-band signal, reduce noise and increase dynamic range.

Model: FBP-922s

Impedance: 50 Ohms

Center frequency: 922.5 MHz

Passband (3dB bandwidth): 920~925 MHz

Band insertion loss: < 3.5 dB

Maximum load power: 20 mW(13 dBm)

Interface: SMA-M, SMA-F

Dimensions:
Product Details
DWM22022304
200 Items
